Best UV Printer for Tumblers
This machine is wonderful if you have the short-run need,there is no need to make the plate or do a lot of jobs before your production,you can just load the artwork,and then print.what you see on your screen will be like on your cup.you can use it in the zoom,museum, shopping mall,exhibition,the basketball or football match scene.Then print souvenir for visitors.
The printing speed is fast,you can print one or two even three within a minute.and the loading -unloading time will as fast as to 3 seconds to get the second printed again.that means,you can print 500 pcs to 1500 pcs per day per printer.actually,one operator can handle 3 printers at the same time.when start to print the next one ,after loading the cup,the operator just need to press the print button,and then the machine's fixture will work automatically to hold and fix the cup,then go to print from right to left,after printing,coming back to the original place and release the fixture to wait for unloading.and then another loop again.it can work so smooth that the operator is not easy make mistakes.and also not easy to be tired.
Easy operation,It is easy to load and unload the cup or bottle we are printing,The fixture is on the right side,when it is ready to print or after completing the printing process,four clamps stretching out in the fixture,so the operator can load the cup onto the clamps.those clamps can support the cup or bottle precisely,then we can press the print button on the operation panel on the machine.the jig on the right side will move left to push and fix the object.in this case, the object can rotate fast with the jigs of two sides.and then,it goes to print,after completing the printing,the fixture with the printed object comes out from the machine,and the four clamps stretch out again,the jig on the right side move back,the cup or bottle drop down onto the clamps to be supported by them.the operator can take it out from the fixture easily and load another new object.
Specification
|
Items |
Description |
|
Printer Model |
GC-360 |
|
Print Applications |
360 degree print on cups,bottles,tumblers,tapers,cylindrical objects |
|
Printable Length |
10mm-265mm(0.4''-10.5") |
|
Printable Diameter |
40mm-115mm(1.5''-4.5'') |
|
Printable Taper Angle |
0-7degree |
|
Print Resolution |
960×900 dpi or other resolution (optional) |
|
Printhead Quantity |
1-4pcs |
|
Print Configuration |
White+color(2heads) |
|
Print Speed |
Fast to 15 s/ pcs |
|
Ink Type |
Invironment-friendly UV Ink |
|
Curing Type |
UV light instant curing(Water cooling lamp) |
|
Power Requirement |
50/60Hz AC220/110±>10A |
|
Environment Temperature |
20℃ - 30℃ |
|
Environment Humidity |
40% - 65% |
|
Environment Cleanliness |
Similar to office environment |
|
Dimensions(L×W×H) |
1812×660×1820mm |
|
Weight |
300kg |
FAQ
1. Does your print can on tapers or other cups with special shape?
Yes,we have the cylinder,taper and other special shape algorithm that can calculate the inks trace precisely,so that the printer can print correctly.
2.How long it will take if I order a printer?
Generally,we can ship your printer within 15 days,and if you have the customized demand,please contact our sales,and check the lead time again.For example,if you have may cups or bottles,but it is not convenient for you to make these matched jigs,we need you to send them to us,or at least give us their sizes,then we can make these jigs while producing the printer.
